Product Overview
LT-2000T Hybrid Portable Gas Analyzer
Multi-Principle Fusion · Single or Multi-Gas Configurable · All-in-One Solution for Emergency & Field Use
The LT-2000T Hybrid Portable Gas Analyzer is a highly integrated, handheld multi-gas detection device capable of simultaneous analysis of one or multiple gases. It supports common industrial gases including CO, CO₂, H₂, CH₄, O₂, SO₂, NOx, NH₃, N₂, and dew point measurement.
Equipped with an integrated pump-suction sampling system and a precision flow control valve, the analyzer combines multiple high-accuracy sensing technologies-UV absorption, NDIR infrared, laser (TDLAS), electrochemical, and paramagnetic oxygen detection-to deliver reliable performance across applications ranging from emergency response to scientific research.
The unit features a 4.3-inch color touchscreen, stores up to 200,000 data records, and supports one-click USB export to Excel. With IP54 protection, Ex ib IIC T4 intrinsic safety certification, and triple power options (rechargeable Li-ion battery, DC 24V, or AC 220V), the LT-2000T truly enables "measure anywhere, anytime-and take your data with you."
Key Features
✅ Flexible Multi-Gas Configuration – One Device, Endless Possibilities
Supports 1–8 gas combinations (including dew point). Whether you need simple CO leak detection or complex process gas monitoring (e.g., NH₃ + NOx + O₂), the system can be customized to your exact needs-eliminating redundant equipment purchases.
✅ High-Accuracy Multi-Principle Fusion – Superior Anti-Interference
Integrates UV, NDIR, laser, electrochemical, and paramagnetic sensors for optimal selectivity.
- Linearity error: ≤ ±2% F.S.
- Cross-interference error: ≤ ±2% F.S.
- Response time (T₉₀): ≤ 30 seconds
Delivers fast, stable, and trustworthy readings even in challenging environments.
✅ Smart Operation & Efficient Data Management
4.3-inch high-resolution color touchscreen with intuitive UI
Automatic storage of ≥200,000 data points with time-stamp search
One-click USB export to Excel-no software or drivers required-making report generation effortless
✅ Rugged & Safe – Built for Hazardous Environments
IP54 rated: protected against dust and water splashes
Ex ib IIC T4 intrinsic safety certification: approved for use in chemical plants, confined spaces, gas stations, and other hazardous areas
Operates reliably in –20°C to +55°C and 0–95% RH (non-condensing)
✅ Triple Power + Portable Design – Ready for Any Scenario
Built-in high-capacity Li-ion battery for hours of continuous operation
Optional DC 24V (vehicle power) or AC 220V (mains power)
Lightweight, ergonomic handheld design-ideal for overhead work, tight spaces, and mobile inspections
Technical Specifications
|
Parameter |
Specification |
|
Display |
4.3-inch LED color touchscreen |
|
Detectable Gases |
CO, CO₂, H₂, CH₄, O₂, SO₂, NOx, NH₃, N₂, Dew Point (configurable) |
|
Detection Principles |
UV Absorption / NDIR Infrared / Laser (TDLAS) / Electrochemical / Paramagnetic |
|
Response Time (T₉₀) |
≤ 30 seconds |
|
Linearity Error |
≤ ±2% F.S. |
|
Cross-Interference Error |
≤ ±2% F.S. |
|
Signal Output (Optional) |
4–20 mA / RS-485 / Wireless 4G (for remote data transmission) |
|
Protection Rating |
IP54 |
|
Explosion Protection |
Ex ib IIC T4 (Intrinsic Safety) |
|
Operating Environment |
Temperature: –20°C to +55°C |
|
Power Supply |
Rechargeable Li-ion battery / DC 24V / AC 220V (triple-mode compatible) |
|
Data Storage |
≥ 200,000 records; USB export to Excel supported |
Applications
Emergency Response & Incident Monitoring
Rapidly identify toxic/combustible gases after chemical spills, fires, or explosions to assess risk levels and guide rescue operations.
01
Confined Space Entry Safety
Continuously monitor O₂, H₂S, CH₄, etc., before, during, and after entry into sewers, tanks, or pits-preventing asphyxiation, poisoning, or explosions.
02
Mobile Patrol & Spot Sampling
Conduct multi-point inspections across industrial parks, municipal pipelines, or facility perimeters to detect fugitive emissions and hidden leaks.
03
Research & Third-Party Testing
Used by universities and accredited labs for teaching, method validation, compliance testing, and traceable data collection.
04
Industrial Process & Emissions Monitoring
Analyze combustion flue gas, chemical reaction streams, or semiconductor process gases to optimize control parameters and ensure regulatory compliance.
05
Why Choose Our LT-2000T Portable Hybrid Gas Analyzer?
Versatile Gas Coverage: Supports single or multi-component analysis of CO, CO₂, H₂, CH₄, O₂, and more-including dew point. The built-in pump and flow control valve ensure precise, stable, and interference-resistant measurements.
User-Friendly Data Handling: The 4.3-inch color touchscreen simplifies operation. With 200,000+ data points stored and one-click Excel export via USB, data management is fast, easy, and audit-ready.
Built for Harsh & Hazardous Conditions: IP54 protection and Ex ib IIC T4 certification make it safe for use in chemical plants and confined spaces. Triple power options and wide environmental tolerance (–20°C to 55°C, 0–95% RH) ensure reliability anywhere.
Ideal for Mobile & Emergency Use: Lightweight and handheld, with rapid response (≤30 s T₉₀), it delivers actionable insights within seconds-critical for emergency decisions and field inspections.
High Precision for Professional Applications: Combines UV, NDIR, and other advanced sensing methods. With linearity and interference errors both ≤ ±2% F.S., it meets the demanding accuracy requirements of research, industrial process control, and emissions compliance.
FAQ
Q1: What gases can it detect? Can I use it for just one gas?
A1: Yes. It supports CO, CO₂, H₂, CH₄, O₂, SO₂, NOx, NH₃, N₂, and dew point. You can configure it for single-gas or multi-gas analysis based on your mission.
Q2: How is data stored and exported?
A2: The device automatically saves up to 200,000 records. After testing, simply plug in a USB drive and export all data directly to Excel-no software needed.
Q3: Can it be used in chemical plants or confined spaces?
A3: Absolutely. It carries Ex ib IIC T4 intrinsic safety certification and IP54 protection, and operates reliably in –20°C to 55°C and high-humidity, dusty environments-designed specifically for high-risk zones.
Q4: Is it suitable for emergency response or mobile inspections?
A4: Yes. Its lightweight handheld design, built-in battery, and ≤30-second response time allow rapid deployment and instant decision-making in critical situations.
Q5: Is the accuracy sufficient for research or industrial use?
A5: Definitely. With multi-principle sensors and errors ≤ ±2% F.S. for both linearity and interference, it meets the high-precision demands of scientific research, process optimization, and regulatory compliance.
