Product Overview
LT-3001 Series Flue Gas Analyzer
Industrial-Grade CEMS for Fixed Pollution Sources · UV-DOAS Technology · Real-Time SO₂/NO/NO₂ Monitoring
The LT-3001 Series Flue Gas Analyzer is a professional online continuous emission monitoring system (CEMS) designed for high-emission industries, including power generation, petrochemicals, metallurgy, cement, and waste incineration.
Based on advanced Ultraviolet Differential Optical Absorption Spectroscopy (UV-DOAS), it delivers real-time or offline measurement of key pollutants-SO₂, NO, and NO₂-along with critical flue gas parameters, even in high-humidity, high-dust, and multi-component environments.
As a core tool for implementing China's Air Pollution Prevention and Control Regulations, this system not only ensures enterprises meet emission limits and pass environmental acceptance inspections, but also provides high-fidelity data to support:
- Boiler combustion optimization
- FGD/SCR system commissioning
- VOCs abatement efficiency evaluation
It is certified for deployment at all types of fixed-source emission points, including:
✅ Power plant boilers & industrial kilns
✅ Metallurgical furnaces & cement rotary kilns
✅ Outlet of desulfurization/denitrification (FGD/SCR) systems
✅ VOCs treatment facility exhaust stacks
Technical Specifications
|
Parameter |
Specification |
|
Target Gases |
SO₂, NO, NO₂ |
|
Detection Principle |
UV-DOAS (Ultraviolet Differential Optical Absorption Spectroscopy) |
|
Measurement Range |
0–50 mg/m³ (customizable for low/high concentration scenarios) |
|
Accuracy |
≤ ±2% F.S. |
|
Repeatability |
≤ ±2% F.S. |
|
Drift (30 days) |
≤ ±2% F.S. |
|
Resolution |
0.01 mg/m³ |
|
Response Time (T₉₀) |
≤ 30 seconds |
|
Warm-Up Time |
≤ 30 minutes |
|
Sample Temperature |
≤ 800°C |
|
Sample Flow Rate |
1500 mL/min |
|
Operating Environment |
–10°C to +55°C (explosion-proof and thermal insulation options available) |
|
Power Supply |
220 V AC, < 3 kW |
|
Outputs |
• RS-485 |
|
Weight |
6 kg |
|
Protection Rating |
IP-rated (dust/water resistant); explosion-proof version available |
Key Features
✅ High Precision with Imported Core Components
Equipped with original imported UV light source, UV-DOAS sensor module, and high-temperature optical cell, the system achieves T₉₀ < 30 s response, excellent repeatability, and strong immunity to water vapor, dust, and background gas interference.
✅ Rugged Industrial Design – Built for Harsh Conditions
- IP-rated enclosure for dust and moisture resistance
- Available in standard and explosion-proof (Ex d) versions
- Infrared remote control enables parameter setup without opening the cabinet-enhancing safety and operational efficiency
✅ Regulatory-Compliant Data Transmission
Fully compliant with China's HJ/T 212-2017 standard for online pollution monitoring. Supports direct upload to national, provincial, and municipal environmental supervision platforms via 4–20 mA, RS-485, or digital protocols-meeting mandatory compliance and audit requirements.
✅ Smart Data Management – Low Operational Burden
- Stores ≥300,000 data records onboard
- Customizable logging intervals (e.g., 1 sec, 1 min, 1 hr)
- Remote data transmission eliminates manual logging-enabling true unattended continuous monitoring
Applications
Power Generation
Continuous emission monitoring (CEMS) for coal/gas-fired boilers to ensure ultra-low emission compliance.
Petrochemicals
SO₂/NOₓ monitoring at refinery tail gas stacks and VOCs treatment outlets to prevent regulatory violations.
Steel & Metallurgy
Real-time pollutant tracking from sintering machines, blast furnaces, and converters-supporting green transformation.
Chemical Industry
Emission monitoring at reactors, crackers, and absorption towers to guarantee process safety and environmental compliance.
Cement Production
NOₓ/SO₂ measurement in kiln and precalciner flue gas to optimize SNCR ammonia injection strategies.
Waste-to-Energy
Simultaneous detection of acid gases and nitrogen oxides to ensure effective dioxin co-control.
Why Choose This Flue Gas Analyzer?
Precision You Can Trust
UV-DOAS + imported optics deliver ≤±2% F.S. accuracy-even in complex, wet, dusty flue gas streams.
Built to Last – 24/7 Reliability
Industrial-grade construction withstands high temperature, corrosion, and vibration-ideal for chemical plants and steel mills.
Operational Efficiency Boost
30-second response + infrared remote + auto-upload = minimal manual intervention, lower labor costs, faster decision-making.
Regulatory Ready – Audit Proof
Fully compliant with HJ/T 212-2017; data is traceable, verifiable, and accepted by environmental authorities.
Low TCO – No Consumables, Easy Maintenance
Optical method = no sensors to replace. Optional explosion-proof or heated enclosures extend service life. Fast local support minimizes downtime.
Fully Customizable
Tailor gas ranges, outputs, and housing to your industry-whether power, chemicals, metallurgy, or waste management.
FAQ
Q1: What gases can it measure, and can the range be adjusted?
A1: Standard configuration measures SO₂, NO, and NO₂. Default range: 0–50 mg/m³, but fully customizable for high-sulfur coal boilers, low-NOₓ burners, or other specific applications to ensure optimal accuracy.
Q2: How does it ensure long-term accuracy and stability?
A2: The system uses UV-DOAS spectroscopy, imported UV source/sensors, and a high-temperature optical path-minimizing drift and interference. Performance specs: accuracy, repeatability, and drift all ≤±2% F.S., with 0.01 mg/m³ resolution.
Q3: Can data be sent directly to government environmental platforms?
A3: Yes. It fully complies with HJ/T 212-2017 and supports direct integration with national/provincial/municipal monitoring networks via RS-485, 4–20 mA, or digital interfaces-no gateway needed.
Q4: Can it operate in extreme temperatures or explosive areas?
A4: Standard operating range: –10°C to +55°C. With optional thermal insulation or explosion-proof housing, it can be deployed in harsh or hazardous zones (e.g., refineries, chemical plants). Two models available: standard and Ex d explosion-proof.
Q5: What is the data storage capacity, and can I set the logging interval?
A5: Onboard memory stores ≥300,000 data points. Users can customize the sampling interval (e.g., every 1 second for process tuning, or every hour for compliance reporting)-flexible for both engineering and regulatory needs.
